Fuego 250ºF Temp Rise Door- Mineral Fiber Core


The Fuego 250˚F temperature-rise rated door will allow the unexposed side of the door to only reach a maximum of 250˚F during the first 30 minutes of the fire test.
Fuego is designed specifically for openings, such as stairwells, requiring conformance to NFPA-80 or similar fire protection recommendations for maximum temperature rise requirements.


Fuego Fire Doors
Fuego is designed specifically for openings, such as stairwells, requiring conformance to NFPA-80 or similar fire protection recommendations for maximum temperature rise requirements.
Constructed with smooth, flush face sheets and neat hemmed edge seams (seamless available), it can be furnished for use with appropriate frame, hardware, and exit devices as required.

250˚F Temperature Rise Fire Doors.
Solid Mineral Fiber Core - Steel Glazing Trim.
UL label: classified for up to 3 hours.
Class A, B, C, D and E with 30 minute temperature rise of LESS than 250 degrees Fahrenheit.

Maximum size:
  • Gauges 18 (1.25mm) or 16 (1.5mm) steel face sheets
  • Single: 4'0" (1,219mm) X 8'0" (2,438mm)
  • Pair: 7'4" (2,235mm) X 7'2" (2,184mm)
  • Pair: 8'0" (2,438mm) X 8'0" (2,438mm) 1-1/2 hour
  • Latch set: UL listed, minimum throw 1/2" (12.7mm) single and 5/8" (15.875mm) pair
  • Classified for use with all labeled fire exit hadrware.
  • High recycled steel content for LEED points.
Tested and approved for use Internationally under UL 10C and BS476 Part 22, 1987 for 30, 60, 120, and 240 minutes.
